Updating Custom Branding to Tailwind v4 at dFlow

Avatar
Pavan Bhaskar
28 Aug, 2025
dflow

We recently updated dFlow Custom Branding logic to Tailwind V4. Here’s a detailed guide of the steps we took to make Tailwind V4 work seamlessly with Custom Branding.

How Custom Branding works

Here's a demo of how customize color-palette, font-family from admin-panel.



Implementation

  • We've created a payload-global theme to store shadcn color-palette, font-family.
1// src/payload/globals/theme.ts
2import type { GlobalConfig, Field } from 'payload'
3import { z } from 'zod'
4

5const validateURL = z
6  .string({
7    required_error: 'URL is required',
8  })
9  .url({
10    message: 'Please enter a valid URL',
11  })
12

13const fontValidation = (
14  value: string | string[] | null | undefined,
15): true | string => {
16  // Ensure value is a string, as it can also be an array or null/undefined
17  if (typeof value === 'string') {
18    const { success } = validateURL.safeParse(value)
19    return success || 'Google Font URL is invalid'
20  }
21  return 'Google Font URL is invalid'
22}
23

24const fontConfig = ({
25  remoteFont,
26  fontName,
27}: {
28  remoteFont: string
29  fontName: string
30}): Field[] => [
31  {
32    name: 'customFont',
33    label: 'Custom Font',
34    type: 'upload',
35    relationTo: 'media',
36    admin: {
37      width: '50%',
38      condition: (_data, siblingData) => {
39        return siblingData.type === 'customFont'
40      },
41    },
42  },
43  {
44    name: 'remoteFont',
45    type: 'text',
46    required: true,
47    label: 'Google Font URL',
48    admin: {
49      width: '50%',
50      condition: (_data, siblingData) => {
51        return siblingData.type === 'googleFont'
52      },
53    },
54    defaultValue: remoteFont,
55    validate: fontValidation,
56  },
57  {
58    name: 'fontName',
59    type: 'text',
60    required: true,
61    label: 'Font Name',
62    admin: {
63      width: '50%',
64      condition: (_data, siblingData) => {
65        return siblingData.type === 'googleFont'
66      },
67    },
68    defaultValue: fontName,
69  },
70]
71

72export const Theme: GlobalConfig = {
73  slug: 'theme',
74  fields: [
75    {
76      type: 'row',
77      fields: [
78        {
79          type: 'group',
80          name: 'lightMode',
81          fields: [
82            // background
83            {
84              type: 'text',
85              name: 'background',
86              admin: {
87                components: {
88                  Field: '@/payload/fields/theme/ColorField',
89                },
90              },
91              required: true,
92              defaultValue: 'oklch(0.973 0.0133 286.1503)',
93            },
94            // foreground
95            {
96              type: 'text',
97              name: 'foreground',
98              admin: {
99                components: {
100                  Field: '@/payload/fields/theme/ColorField',
101                },
102              },
103              required: true,
104              defaultValue: 'oklch(0.3015 0.0572 282.4176)',
105            },
106            // ...add rest colors
107          ],
108        },
109        {
110          type: 'group',
111          name: 'darkMode',
112          fields: [
113            {
114              type: 'text',
115              name: 'background',
116              admin: {
117                components: { Field: '@/payload/fields/theme/ColorField' },
118              },
119              required: true,
120              defaultValue: 'oklch(0.2069 0.0403 263.9914)',
121            },
122            // foreground
123            {
124              type: 'text',
125              name: 'foreground',
126              admin: {
127                components: { Field: '@/payload/fields/theme/ColorField' },
128              },
129              required: true,
130              defaultValue: 'oklch(0.9309 0.0269 285.8648)',
131            },
132          ],
133        },
134      ],
135    },
136    // Fonts
137    {
138      type: 'group',
139      name: 'fonts',
140      fields: [
141        {
142          type: 'group',
143          name: 'display',
144          label: 'Display Font',
145          fields: [
146            {
147              name: 'type',
148              type: 'radio',
149              required: true,
150              options: [
151                {
152                  label: 'Custom Font',
153                  value: 'customFont',
154                },
155                {
156                  label: 'Google Font',
157                  value: 'googleFont',
158                },
159              ],
160              defaultValue: 'googleFont',
161            },
162            {
163              type: 'row',
164              fields: fontConfig({
165                remoteFont:
166                  'https://fonts.googleapis.com/css2?family=Geist:wght@100..900&display=swap',
167                fontName: 'Geist',
168              }),
169            },
170          ],
171        }
172      ],
173    },
174    // Radius
175    {
176      admin: {
177        components: {
178          Field: '@/payload/fields/theme/RadiusField',
179        },
180      },
181      type: 'select',
182      name: 'radius',
183      options: [
184        {
185          label: 'None',
186          value: 'none',
187        },
188        {
189          label: 'Small',
190          value: 'small',
191        },
192        {
193          label: 'Medium',
194          value: 'medium',
195        },
196        {
197          label: 'Large',
198          value: 'large',
199        },
200        {
201          label: 'Full',
202          value: 'full',
203        },
204      ],
205      required: true,
206      defaultValue: 'medium',
207    },
208  ],
209}
  • We've created custom UI components which makes customization easier.
1// src/payload/fields/theme/ColorField.tsx
2'use client'
3

4import { useField, useForm, useFormFields } from '@payloadcms/ui'
5import { TextFieldClientProps } from 'payload'
6

7

8function parseCssVars(css: string): Record<string, string> {
9  const result: Record<string, string> = {}
10

11  // Match all lines like --key: value;
12  const matches = css.match(/--[\w-]+:\s*[^;]+;/g)
13  if (!matches) return result
14

15  for (const match of matches) {
16    const [key, ...rest] = match.split(':')
17    let value = rest.join(':').replace(/;/g, '').trim()
18

19    // Remove leading '--' and convert to camelCase
20    const cleanedKey = key.trim().replace(/^--/, '')
21    const camelKey = cleanedKey.replace(/-([a-z0-9])/gi, (_, char) =>
22      char.toUpperCase(),
23    )
24

25    // ✅ Normalize different color formats
26    if (/^hsl\(/i.test(value)) {
27      // already valid hsl
28      result[camelKey] = value
29    } else if (/^rgb\(/i.test(value)) {
30      result[camelKey] = value
31    } else if (/^oklch\(/i.test(value)) {
32      result[camelKey] = value
33    } else if (/^oklab\(/i.test(value)) {
34      result[camelKey] = value
35    } else if (/^#[0-9a-f]{3,8}$/i.test(value)) {
36      // hex → keep as hex
37      result[camelKey] = value
38    } else {
39      // fallback: wrap raw string
40      result[camelKey] = value
41    }
42  }
43

44  return result
45}
46

47const ColorField = ({ ...props }: TextFieldClientProps) => {
48  const { value = '', setValue } = useField<string>({ path: props.path })
49  const { fields, dispatch } = useFormFields(([fields, dispatch]) => ({
50    fields,
51    dispatch,
52  }))
53  const { setModified } = useForm()
54

55  const label = typeof props.field.label === 'string' ? props.field.label : ''
56

57  return (
58    <>
59      <label htmlFor={props.path}>{label}</label>
60

61      <div className='color-field-container'>
62        <div
63          className='color-field-preview'
64          style={{ backgroundColor: value }}
65        />
66

67        <input
68          type='text'
69          id={props.path}
70          value={value}
71          onChange={e => {
72            const newValue = e.target.value
73

74            if (newValue.includes(':root') || newValue.includes('--')) {
75              const lightTheme = parseCssVars(newValue.split('.dark')[0])
76              const darkTheme = parseCssVars(newValue.split('.dark')[1] || '')
77

78              // update lightTheme
79              for (const [variableName, value] of Object.entries(lightTheme)) {
80                if (fields[`lightMode.${variableName}`]) {
81                  dispatch({
82                    type: 'UPDATE',
83                    path: `lightMode.${variableName}`,
84                    value,
85                    valid: true,
86                  })
87                }
88              }
89

90              // update darkTheme
91              for (const [variableName, value] of Object.entries(darkTheme)) {
92                if (fields[`darkMode.${variableName}`]) {
93                  dispatch({
94                    type: 'UPDATE',
95                    path: `darkMode.${variableName}`,
96                    value,
97                    valid: true,
98                  })
99                }
100              }
101

102              setModified(true)
103            } else {
104              // todo: parse value to hsl
105              setValue(newValue)
106            }
107          }}
108        />
109      </div>
110    </>
111  )
112}
113

114export default ColorField
  • Radius field is used to control default border-radius.
1// src/payload/fields/theme/RadiusField.tsx
2'use client'
3

4import { useField } from '@payloadcms/ui'
5import { SelectFieldClientProps } from 'payload'
6

7const RadiusField = ({ ...props }: SelectFieldClientProps) => {
8  const { value = '', setValue } = useField<string>({ path: props.path })
9  const label = typeof props.field.label === 'string' ? props.field.label : ''
10  const options = props.field.options
11

12  return (
13    <>
14      <label>{label}</label>
15

16      <div className='radius-field-container'>
17        {options.map((field, index) => {
18          const option =
19            typeof field === 'object'
20              ? { label: field.label, value: field.value }
21              : { label: field, value: field }
22

23          return (
24            <label
25              data-option-active={value === option.value}
26              className='radius-field-label'
27              key={index}>
28              <input
29                type='radio'
30                name='radius'
31                value={option.value}
32                onChange={e => {
33                  setValue(e.target.value)
34                }}
35              />
36              <div
37                className='radius-option'
38                style={{ borderTopLeftRadius: `var(--radius-${option.value})` }}
39              />
40

41              <span className='radius-option-name'>{option.value}</span>
42            </label>
43          )
44        })}
45      </div>
46    </>
47  )
48}
49

50export default RadiusField
  • Add this in custom.scss for styling UI-components in payload-admin panel.
1// src/app/payload/custom.scss
2$radius-none: 0rem;
3$radius-small: 0.25rem;
4$radius-medium: 0.375rem;
5$radius-large: 0.5rem;
6$radius-full: 999rem;
7

8:root {
9  --radius-none: #{$radius-none};
10  --radius-small: #{$radius-small};
11  --radius-medium: #{$radius-medium};
12  --radius-large: #{$radius-large};
13  --radius-full: #{$radius-full};
14}
15

16// Color field styles
17.color-field-container {
18  display: flex;
19  gap: 0.5rem;
20  margin-top: 0.25rem;
21  margin-bottom: 1rem;
22

23  & .color-field-preview {
24    width: 2rem;
25    height: 2rem;
26    border-radius: 0.25rem;
27  }
28}
29

30// Radius field styles
31.radius-field-container {
32  display: flex;
33  justify-content: space-between;
34  max-width: 30rem;
35  margin-top: 0.5rem;
36

37  & .radius-field-label[data-option-active='true'] {
38    border-color: #8b5cf6;
39  }
40}
41

42.radius-field-label {
43  position: relative;
44  border: 1px solid #334154;
45  border-radius: 0.25rem;
46  cursor: pointer;
47

48  & .radius-option-name {
49    position: absolute;
50    bottom: -2rem;
51  }
52}
53

54.radius-field-label input {
55  position: absolute;
56  appearance: none;
57  inset: 0;
58  height: 100%;
59  width: 100%;
60}
61

62.radius-field-label .radius-option {
63  height: 32px;
64  width: 32px;
65  background: rgba(139, 92, 246, 0.3137254902);
66  border-left: 2px solid #8b5cf6;
67  border-top: 2px solid #8b5cf6;
68  margin: 1rem;
69  position: relative;
70}
  • Fetching the theme global in nextjs root-layout.
1// src/app/layout.tsx
2import configPromise from '@payload-config'
3import { getPayload } from 'payload'
4import Branding from '@/components/Branding'
5

6export default async function RootLayout({
7  children,
8}: {
9  children: React.ReactNode
10}) {
11  const payload = await getPayload({
12      config: configPromise,
13  })
14

15  const theme = await payload.findGlobal({
16      slug: 'theme',
17  })
18

19  return (
20    <html>
21      <head>
22        {theme && <Branding theme={theme} />}
23      </head>
24

25      <body>
26        {children}
27      </body>
28    </html>
29  )
30}
  • Rendering <Branding> component which appends <style> tag in <head>, this overrides the css-variables from the global.css file.
1// src/componentes/Branding.tsx
2import { env } from 'env'
3import { Fragment } from 'react'
4

5import { fontType, getCSSAndLinkGoogleFonts, mimeTypes } from '@/lib/googleFont'
6import type { Theme as ThemeType } from '@/payload-types'
7

8type ThemeStylesType = {
9  colors: ThemeType['lightMode']
10  fontName: {
11    display: string
12    body: string
13  }
14  radius: ThemeType['radius']
15}
16

17const borderRadius = {
18  none: `0rem`,
19  small: `0.25rem`,
20  medium: `0.375rem`,
21  large: `0.5rem`,
22  full: `999rem`,
23} as const
24

25// All the color variables are generated using generateThemeStyles function for light & dark mode
26function generateThemeVariables({ colors, radius, fontName }: ThemeStylesType) {
27  return `
28      --primary: ${colors.primary};
29      --primary-foreground: ${colors.primaryForeground};
30      --secondary: ${colors.secondary};
31      --secondary-foreground: ${colors.secondaryForeground};
32      --accent: ${colors.accent};
33      --accent-foreground: ${colors.accentForeground};
34      --background: ${colors.background};
35      --foreground: ${colors.foreground};
36      --card: ${colors.card};
37      --card-foreground: ${colors.cardForeground};
38      --popover: ${colors.popover};
39      --popover-foreground: ${colors.popoverForeground};
40      --muted: ${colors.muted};
41      --muted-foreground: ${colors.mutedForeground};
42      --destructive: ${colors.destructive};
43      --border: ${colors.border};
44      --input: ${colors.input};
45      --ring: ${colors.ring};
46      --chart-1: ${colors.chart1};
47      --chart-2: ${colors.chart2};
48      --chart-3: ${colors.chart3};
49      --chart-4: ${colors.chart4};
50      --chart-5: ${colors.chart5};
51      --sidebar: ${colors.sidebar};
52      --sidebar-foreground: ${colors.sidebarForeground};
53      --sidebar-primary: ${colors.sidebarPrimary};
54      --sidebar-primary-foreground: ${colors.sidebarPrimaryForeground};
55      --sidebar-accent: ${colors.sidebarAccent};
56      --sidebar-accent-foreground: ${colors.sidebarAccentForeground};
57      --sidebar-border: ${colors.sidebarBorder};
58      --sidebar-ring: ${colors.sidebarRing};
59      --font-display: ${fontName.display || ''};
60      --font-body: ${fontName.body || ''};
61      --border-radius: ${borderRadius[radius]};
62  `
63}
64

65const Branding = async ({ theme }: { theme: ThemeType }) => {
66  const { lightMode, darkMode, radius, fonts } = theme
67

68  const displayFont =
69    fonts.display.type === 'customFont'
70      ? typeof fonts.display.customFont === 'object'
71        ? {
72            url: fonts.display.customFont?.url ?? '',
73            format:
74              mimeTypes[
75                ((fonts.display?.customFont?.url ?? '').split('.')?.[1] ??
76                  'otf') as keyof typeof mimeTypes
77              ],
78            fontName: 'Display',
79          }
80        : undefined
81      : {
82          googleFontURL: fonts.display.remoteFont ?? '',
83          fontName: fonts.display.fontName ?? '',
84        }
85

86  const bodyFont =
87    fonts.body.type === 'customFont'
88      ? typeof fonts.body.customFont === 'object'
89        ? {
90            url: fonts.body.customFont?.url ?? '',
91            format:
92              mimeTypes[
93                ((fonts.body?.customFont?.url ?? '').split('.')?.[1] ??
94                  'otf') as keyof typeof mimeTypes
95              ],
96            fontName: 'Body',
97          }
98        : undefined
99      : {
100          googleFontURL: fonts.body.remoteFont ?? '',
101          fontName: fonts.body.fontName ?? '',
102        }
103

104  const googleFontsList = [
105    displayFont?.googleFontURL ?? '',
106    bodyFont?.googleFontURL ?? '',
107  ].filter(url => Boolean(url))
108

109  const response = await getCSSAndLinkGoogleFonts({
110    fontUrlList: googleFontsList,
111  })
112

113  const lightModeVariables = generateThemeVariables({
114    colors: lightMode,
115    fontName: {
116      display: displayFont?.fontName ?? '',
117      body: bodyFont?.fontName ?? '',
118    },
119    radius,
120  })
121

122  const darkModeVariables = generateThemeVariables({
123    colors: darkMode,
124    fontName: {
125      display: displayFont?.fontName ?? '',
126      body: bodyFont?.fontName ?? '',
127    },
128    radius,
129  })
130

131  return (
132    <>
133      {displayFont?.url && (
134        <link
135          rel='preload'
136          href={`${env.NEXT_PUBLIC_WEBSITE_URL}${displayFont.url}`}
137          as='font'
138          type={displayFont.format}
139          crossOrigin='anonymous'
140        />
141      )}
142

143      {bodyFont?.url && (
144        <link
145          rel='preload'
146          href={`${env.NEXT_PUBLIC_WEBSITE_URL}${bodyFont.url}`}
147          as='font'
148          type={bodyFont.format}
149          crossOrigin='anonymous'
150        />
151      )}
152

153      {/* If user uploads custom font setting styles of that font */}
154      <style
155        dangerouslySetInnerHTML={{
156          __html: `${
157            displayFont?.url
158              ? `@font-face {
159            font-family: 'Display';
160            src: url(${env.NEXT_PUBLIC_WEBSITE_URL}${displayFont.url}) format(${fontType[displayFont.format]});
161            font-weight: normal;
162            font-style: normal;
163            font-display: swap;
164          }`
165              : ''
166          }\n
167            ${
168              bodyFont?.url
169                ? `@font-face {
170            font-family: 'Body';
171            src: url(${env.NEXT_PUBLIC_WEBSITE_URL}${bodyFont.url}) format(${fontType[bodyFont.format]});
172            font-weight: normal;
173            font-style: normal;
174            font-display: swap;
175          }`
176                : ''
177            }`,
178        }}
179      />
180

181      {/* Link & Style tags are created from googleFonts response */}
182      {response.map(({ cssText, preloadLinks }, index) => (
183        <Fragment key={index}>
184          {preloadLinks.map(({ href, type }) =>
185            href ? (
186              <link
187                rel='preload'
188                as='font'
189                crossOrigin='anonymous'
190                href={href}
191                type={type}
192                key={href}
193              />
194            ) : null,
195          )}
196          <style dangerouslySetInnerHTML={{ __html: cssText }} />
197        </Fragment>
198      ))}
199

200      <style
201        dangerouslySetInnerHTML={{
202          __html: `
203            :root {
204            ${lightModeVariables}
205            }
206            \n
207              .dark {
208                ${darkModeVariables}
209              }
210            `,
211        }}
212      />
213    </>
214  )
215}
216

217export default Branding
  • Pre-fetches the font-url on server-side, so there won't be layout-shifts on client-side
1// src/lib/googleFont.ts
2export const mimeTypes = {
3  woff: 'font/woff',
4  woff2: 'font/woff2',
5  ttf: 'font/ttf',
6  otf: 'font/otf',
7  eot: 'application/vnd.ms-fontobject',
8  svg: 'image/svg+xml',
9} as const
10

11export const fontType = {
12  'font/otf': 'opentype',
13  'font/ttf': 'truetype',
14  'font/woff': 'woff',
15  'font/woff2': 'woff2',
16  'application/vnd.ms-fontobject': 'embedded-opentype',
17  'image/svg+xml': 'svg',
18} as const
19

20export type FontPreloadAttributes = {
21  href: string
22  type: keyof typeof mimeTypes | string
23}
24

25export type ExtractedListType = {
26  preloadLinks: FontPreloadAttributes[]
27  cssText: string
28}
29

30export const getFontMimeType = (url: string) => {
31  const ext = url.split('.').pop() as keyof typeof mimeTypes // Get the file extension
32  return mimeTypes[ext] || 'font/woff2'
33}
34

35export const fetchGoogleFonts = async (fontUrl: string) => {
36  try {
37    const response = await fetch(fontUrl)
38    const cssText = await response.text()
39

40    // Extract font URLs
41    const fontUrls = Array.from(cssText.matchAll(/url\(([^)]+)\)/g)).map(
42      match => match[1].replace(/['"]+/g, ''), // Clean up the URL
43    )
44

45    // Generate preload links as attribute objects
46    const preloadLinks = fontUrls.map(url => ({
47      href: url,
48      type: getFontMimeType(url),
49    }))
50

51    return { preloadLinks, cssText }
52  } catch (error) {
53    console.error('Failed to load Google Fonts:', error)
54    return {
55      preloadLinks: [
56        {
57          href: '',
58          type: '',
59        },
60      ],
61      cssText: '',
62    }
63  }
64}
65

66export const getCSSAndLinkGoogleFonts = async ({
67  fontUrlList,
68}: {
69  fontUrlList: string[]
70}) => {
71  const list: ExtractedListType[] = []
72

73  for await (const fontURL of fontUrlList) {
74    const { preloadLinks, cssText } = await fetchGoogleFonts(fontURL)
75    list.push({ preloadLinks, cssText })
76  }
77

78  return list
79}

That's how we're overriding the shadcn-themes dynamically at run-time!

Migration Guide v3-v4

Previously we've implemented custom-branding in Tailwind v3. Here're migration steps we followed from Tailwind V3-V4.

Step 1:

  • Run tailwind upgrade command, pnpm dlx @tailwindcss/upgrade this does heavy lifting!

Step 2:

  • Note: The above command will replace the shadcn outline variant to -> outline-none so we need to look-out for the shadcn-components
  • Re-initialize shadcn again pnpm dlx shadcn@latest init , this suggested to delete components.json & try-again, I've done that it just made the tailwind.config as empty in components.json
1{
2  "$schema": "https://ui.shadcn.com/schema.json",
3  "style": "new-york",
4  "rsc": true,
5  "tsx": true,
6  "tailwind": {
7    "config": "",
8    "css": "src/app/(frontend)/globals.css",
9    "baseColor": "gray",
10    "cssVariables": true,
11    "prefix": ""
12  },
13  "aliases": {
14    "components": "@/components",
15    "utils": "@/lib/utils",
16    "ui": "@/components/ui",
17    "lib": "@/lib",
18    "hooks": "@/hooks"
19  },
20  "iconLibrary": "lucide"
21}

Step 3:

  • Migrated all tailwind plugins to global.css
1/* global.css */
2@import 'tailwindcss';
3@import 'tw-animate-css';
4

5@plugin "@tailwindcss/typography";

References

These are the steps we did for Tailwind v4 migration. Check out these references! let's us know if there're an alternative approaches for implementing custom-branding. Until then peace✌️



Share:

TwitterLinkedInFacebook
dFlow logodFlow

dFlow simplifies cloud deployments with powerful tools for managing servers, services and domains.

Resources

Company

Compare

© 2025 dFlow. All rights reserved.
Updating Custom Branding to Tailwind v4 at dFlow | dFlow
